5.2KW Hybrid Solar Inverter Price|Wave 5000
5.2KW Hybrid Solar Inverter Feature
5.2KW Hybrid Solar Inverter Characteristic
5.2KW Hybrid Solar Inverter Electrical Parameters
Can Wave 5000 Inverter suitable for use in residential or commercial settings?
Can Wave 5000 inverter be used for off-grid applications?
Our Factory

GP 5KW Solar Inverter Pure Sine Wave Inverter Off grid mppt solar hybrid inverter with remote control_Green Power

Empower your energy independence with the Wave 5.2KW Hybrid Solar Inverter. Seamlessly integrating solar and traditional power sources, it delivers uninterrupted performance. Engineered for efficiency and reliability, this inverter ensures optimal energy utilization for homes and businesses alike. With advanced features like grid-tie functionality and battery backup, it offers versatility for any energy system. Take charge of your energy future today. Click to access exclusive manufacturer pricing and unleash the full potential of renewable energy.

Place Of Origin: Shenzhen, Guangdong Province, China

Model: Wave 5000|Green Power

Certificates: CE、ROHS、IEC62109-1/2、EN61000-6-2/4

MOQ: 1 set Accept; Customization (at least 10 sets)

Payment: T/T, L/C, Western Union

Get Price

Product Detail

Product Tags

5.2KW Hybrid Solar Inverter Feature

Automotive Grade LiFePO4 Cells

Up to 99.9% MPPT capture efficiency

Maximum 18A input current, adaptation to high power components.

Wave 5000,the 5KW Solar inverter comes with a lithium battery activation function and can support both lead-acid and lithium batteries

High Stability and Reliability

Four charging modes: including solar only, utility priority, solar priority, and hybrid charging.

Pure sine wave AC output via SPWM modulation

Simultaneous connection to utility grid/generator and PV(24/7 UPS).

An ON/OFF switch for controlling the AC output

Two output modes: utility bypass or inverter output, ensuring uninterrupted power supply.

User-Friendly

Two output modes: utility bypass or inverter output, ensuring uninterrupted power supply.

Power saving mode automatically reduces power consumption at zero-load

Intelligent adjustable speed fan for efficient heat dissipation, extend the lifespan of the system

Security Protection

Multiple safety protection functions from hardware to software UL / CE Certification.

Equipped with complete short circuit protection, under/over-voltage protection, overload protection, reverse protection, and other safety protection functions.

5.2KW Hybrid Solar Inverter Characteristic

5.2KW Hybrid Solar Inverter Wave 5000 (2)

5.2KW Hybrid Solar Inverter Electrical Parameters

Model	Wave 5000
Inverter Output
Rated Output Power	5000W
Max.Peak Power	10000VA
Rated Output Voltage	EU: 230Vac (L/N/PE single-phase) US/JP: 120Vac (L/N/PE single-phase)
Rated AC Frequency	50/60Hz
Waveform	Pure sine wave
Switch Time	10ms(Typical)
Parallel Capacity	/
Battery
Battery Type	Li-ion / Lead-acid / user-define
Rated Battery Voltage	48Vdc
Voltage Range	40 〜60Vdc
Max.MPPT Charging Current	80A
Max.Mains/Generator Charging Current	EU: 60A US/JP: 40A
Max.Hybrid Charging Current	80A
PV Input
Num. of MPP Trackers	1
Max.PV array power	5200W
Max.input current	18A
Max.Voltage of Open Circuit	500Vdc
MPPT Voltage Range	125 〜450Vdc
MPPT Tracking Efficiency	99.90%
Mains / GeneratorInput
Input Voltage Range	EU: 170~280Vac US/JP: 90~140Vac
Frequency Range	50/60Hz
Bypass Overload Current	40A
General
Dimensions	426322126mm
Weight	10.9kg
Protection Degree	IP20, Indoor Only
Operating Temperature Range	-15~55C
Communication Method	RS485 / CAN / USB / dry contact
Noise	<60dB
Cooling Method	Intelligent Fan
Warranty	2 Years
Certification
Safety	CE (IEC62109-1) CETL (UL 1741; CSA C22.2 No.107.1) CE (IEC62109-1)
EMC	EN61000

Can Wave 5000 Inverter suitable for use in residential or commercial settings?

Yes, the Wave 5000 inverter is suitable for use in both residential and commercial settings. With a rated output power of 5000W and a maximum peak power of 10000VA, it is capable of powering a wide range of appliances and devices. Additionally, its pure sine wave output waveform ensures stable and clean power, making it suitable for sensitive electronics. The Wave 5000 inverter can be used as a backup power source during power outages or integrated with solar panels for a complete solar power system. Its versatility and reliability make it an excellent choice for both residential and commercial applications.

Can Wave 5000 inverter be used for Off-grid Applications?

Yes,the Wave 5000 inverter is suitable for both on-grid and off-grid applications. With its high max. MPPT charging current of 80A and battery compatibility with Li-ion, lead-acid, and user-defined batteries, it is capable of providing reliable power in off-grid situations. Additionally, its pure sine wave output waveform ensures clean and stable power for sensitive electronics.

5.2KW Hybrid Solar Inverter Wave 5000 (3)

5.2KW Hybrid Solar Inverter Wave 5000 (1)

Our Factory

FireflyTree use advanced production equipment to ensure the precision and reliability of our solar inverter components. Our equipment maintenance personnel perform daily maintenance.

Our production team follows the engineering department's procedures to ensure reliable production of industrial products. Qualified production personnel are the reliable guarantee for industrial product manufacturing.

Solar inverter components require the use of advanced chemical adhesives, which need about two hours of stationary time to ensure the inverter’s firmness.

After passing the final inspection process, the completed solar inverters are ready for acceptance.

Professional packaging that meets the inverter's structure can effectively protect the product and facilitate subsequent transportation.

Compared to lithium-ion batteries, the cross-border logistics of inverters is less challenging, but we still insist on the safe transportation of every product.
