3KWh All In One Stackable Energy Storage System |Green Power
3KWh All In One Stackable Energy Storage System Feature
Automotive Grade LiFePO4 Cells
★ Automotive Grade LiFePO4 cells that meet UL /CE certification standards, up to 5000 cycles.
★ Maximum 60A input current, adaptation to high power components.
High Stability and Reliability
★ Our equalization-enabled BMS can regulate cell consistency and safeguard against short circuits and over-current, thereby enhancing battery safety and durability.
★ Simultaneous connection to utility grid/generator and PV
Easy Installation
★ Integrated inverter & battery, All-In-One design for installation, greatly reducing investment and maintenance costs.
★ Stylish and stackable design,for a variety of home use and outdoor application scenarios.
Flexible Storage Capacity and User Friendly design
★ You can use batteries in parallel at the same time, and can easily expand to a maximum of
12.3kwh for your use.
★ With remote WIFI control, Use enhanced security features and multiple safety protection functions from hardware to software
3KWh All In One Stackable Energy Storage System Electrical Parameters
| TYPE | 3KW (Inverter) + 3KWh (Battery) |
| Battery type | LiFePO4 |
| Battery Normal Capacity | 3.07KWh |
| Rated Battery Voltage | 51.2V |
| Operating Voltage Range | 40~58.4V |
| Max. Continuous Charge/Discharge Current | 60A |
| Max. Expandable Battery Capacity | 12.3KWh |
| Inverter Rated Output Power | 3000W |
| Inverter Max. Peak Powe | 6000VA |
| Inverter Rated Output Voltage | EU: 230Vac（L/N/PE single-phase） US/JP: 120Vac（L/N/PE single-phase） |
| Max. PV Array Power | 3400W |
| MPPT Operating Voltage Range | 60~115Vdc |
| Operating Temperature Range | Charge: 0<T<55℃; Discharge: -20<T<55℃ |
| Installation Method | Stack |
| Weight | 45kg |
| Dimensions | 450 × 450 × 400mm |
How Does A 3KWh All In One Stackable Energy Storage System Work?
The Green Power Stackable Energy Storage System 3kW (INVERTER) + 3kWh (BATTERY) is a portable home and outdoor energy storage solution with a massive 3000Wh capacity.
It is designed for situations where access to wall outlets is limited and for outdoor activities. With its stackable design, it integrates an inverter and energy storage battery, offering a sleek appearance and easy installation.
The Green Power Stackable Energy Storage System can be effortlessly expanded up to a maximum of 12kWh, providing a rated output power of up to 3000W. It supports everyday household appliances such as TVs, refrigerators, LED lights, water heaters, cameras, computers, ventilators, routers, mobile phones, and more.
The Green Power Stackable Energy Storage System work: with The inverter stably and safely receives and converts electricity from sources like photovoltaic panels and the grid. The inverter converts the PV power into stable AC power to supply the household load and stores the excess power in the lower energy storage battery, it enables comfortable off-grid living for both home and outdoor use, lasting for half a day or longer.
How Much A 3KWh All In One Stackable Energy Storage System Cost?
| COMMERCIAL TERMS | |
| Sample Time |
35 Days |
| Lead Time |
55 Days |
| Payment |
30-50% Deposit in Advanced, Rest% Made Before Shipment |
Why Choose GreenPower
For home battery backup products equipped a large number of internal battery cells, we work with clients to inspect each node on-site after the batteries are completed.
GreenPower places a strong emphasis on product design and engineering for mass production. Colleagues in our Quality Engineering Department have extensive experience in large-scale quality production.
GreenPower has complete testing equipment to ensure high-standard testing and inspection support for products during the sample and mass production stages.
Given the unique safety requirements of lithium-ion products, GreenPower insist on testing each product's performance after it has been left stationary.
In the event of occasional delays in customer delivery times, GreenPower’s warehouse provides free storage for completed orders for a certain period.
With our extensive experience in cross-border logistics, we are familiar with China's import and export regulatory agencies and can assist clients with customs clearance and other related processes.
